Security Parcel inspection X Ray Baggage Scanner, Check-in system
for Security System
Technical Specifications
Tunnel Size : 1000(W)×1000(H)mm
Power Requirement: 220V AC (±10%) 50±3Hz
Power consumption: 1.0KW (Max)
Noise level: <58dB
Conveyor Speed: 0.22m/s
Conveyor Max Load: 1000 kg
Alarm by sounds & light::Alarm by sounds and light when conform to
condition.
Network interface:Could be connect local area network and support
multi-terminal check baggage at same times
Safety ray:Transmit ray under automatic control, avoids the miss
Image monitoring for user-friendly:The monitor use fold, rotary
system, operators adjusts the monitor position willfully according
to own need, reduces wearily.
X-Ray Generator Specifications
Dual view: two X-ray generators
Voltage: 150-200KV (Adjustable)
Tube Current: 1.0 ~1.5mA (Adjustable)
Cooling: Sealed oil bath with forced air
Duty Cycle: Rated for 100％Duty Cycle
Beam Direction: Downward and sideward
Beam Angle: 80°
Detector: L-shaped Array *2
Image Display
2* 19’’ High Resolution LCD Monitor
Display Resolution: 1280*1024;24 bit/pixel Color, dual view image
Contrast Sensitivity: 24 Visible Levels,4096 Gray Level
Image storage: 100,000 pictures in real time (can be customized)
Zoom: 64 Times Enlarge, Whole screen continuous observation
Multi-Energy (M) color material identification: Organic objects in
orange color, inorganic objects in blue color, mixture in green
color
Threat image projection (TIP), assist to detect drug and explosive
powder
Edge enhancement: Object contour edge is more distinct
Super image enhancement: Image detail is more distinct
Magnifier: function of partial enlargement
Brightening/dimming: increase brightness of image/decrease
brightness of image
Image recurrence: display previous twenty images and process any
one of them
Image restoration: restore image to initial status at the time of
stopping conveyor
Image storing: real time store any image and process it in
operation status
Multi-energy function
Magnifier: Local amplification function
Brightening/darken: Increase the brightness of the image/ Reduce
the brightness of the image
Multi-energetic distinguish objects:organic objects in orange,
inorganic objects in blue, mixture in green
High-energy/low energy:switch from high energy to low energy Assist
to detect drug and explosive powder
| Specifications: |
| Model Number | SF100100 |
| Passageway Size | 1000(W)*1000(H) mm |
| Penetration | mm Steel plate |
| Belt Max Load: | 200Kg |
| Dose per inspection: | <2Gy/h |
| Resolving power | 38AWG |
| Film Safety | Guarantee ISO1600 Film |
| X-Ray leakage | <0.2µGy/h |
| Ray beam spread angle | 80 degree |
| Tube Voltage | 150-200KV |
| Tube power | 1-1.5mA |
| Cooling/work Cycle | Sealed Oil Cooling /100% |
| Multi-energy/Distinguish objects | organic objects in orange,inorganic objects in blue,mixture in
green |
| Belt speed | 0.22m/s (adjustable) |
| Display | HD 19’’LCD display
|
| High-energy/low energe | Two kinds of energy switch display |
| Image restoration | Image display restore the origional status |
| Certificates | CE /OHSAS18001/ISO19001/ISO9001 |
Special features:
Varying effects image display and picture processing
based on medical CT scanning image technology; 1000M channel high
speed data acquisition.
input automatically protection is safer.
big size screen display, 24 inch medical screen display, provides
focus image, exact-observation and easy to tell images, also can be
full image.
keyboard and mouse control
Be with Industrial computer system, and Windows operation.
Flexible combination: CT scanning, Intensifier, panel can be chose.
Work power 150-200KV, in order to satisfy the different
requirement.
Defective products with NG choose, automatically stop and reject.
Environment Specifications:
Operating temperature/humidity: 0℃ ~ 45℃/20% ~ 95% (Non-condensing)
Storage temperature/humidity: -20℃ ~ 60℃/20% ~ 95% (Non-condensing)
Packing and Shipment:
| Packing details | carton packing |
| 1 set/ctn , 2 wooden |
| Packing Size: (L)2800*1450*2080mm & 1440*1250*710mm |
| Gross Weight:1200 KG |
| Payment terms | T/T, Western Union, Cash,L/C |
| Shipping methods | By air (5-7days, most expensive) |
| By express (3-7days, more expensive) |
By sea (15-28days, cheapest)
|
